Honeywell Vista 20p Installation Guide

The is a versatile, reliable dialer for your alarm system. The speed of the primary internet path and the reliability that the back up 4G cellular path offers is bar none. Check out the which is great tool that walks you through the installation process step by step. If this is a fresh installation follow these steps: 1. Test signal strength and determine location.

Index of /manuals/Ademco/Control Panels/Vista-20P. Parent Directory Vista-20P 1361X10 Transformer Kit.pdf Vista-20P Comparison Sheet.pdf Vista-20P Data Sheet.pdf Vista-20P X-10 Powerhorn Info.pdf Vista-20P v1 Installation Manual.pdf Vista-20P v1 Smoke Relay Wiring.pdf Vista-20P v1 User Manual.pdf. The image of the Honeywell Vista 20p wiring diagram is small, but you can click to enlarge it. Ademco Vista 20P wiring diagram-Click to Enlarge. (Click or tap on image to enlarge). Also, I highly recommend that you download a free copy of the complete Ademco manual, which will include a full-size image of the wiring.

(Install guide page 2-1) Connect the unit's battery back up and AC power supply. Ideally the communicator can sit beside the panel so boot it up locally and check the LEDs for signal strength. You will need at least 3 LEDS for minimum signal to function. This is a rough test so if you have 3 or more just move to the next step. Your monitoring provider will be able to do more accurate testing once registered. Mount the communicator.

(Install guide page 2-2) Simply mount the unit to the wall. This unit does not weigh very much so using zip-its or the included wall anchors will work well.

Line up the back plate on the wall and trace the keyholes while the unit is level. Then pre-drill for the anchors. M3 Raw Drive Recovery Full Crack. Make sure to use a bit that is slightly larger than the small end of the anchor. This way the anchor will slide in snug. After you push in the anchors, screw in the screws leaving space for the wall plate to sit on before tightening them all the way down.
